1-   Type: 6-way mobile power source equipment

2-   Movement ability: metal box frame which has wheels fixed to the base for

       ease of movement

3-   Input power: 380  VAC  *   (3 phase)   *   90 AMP per Phase   *   50 Hz

4-   Output power:  60 KVA

5-   Protection: 230-VAC Control Circuit: 5 AMP circuit breaker

6-   Protection: Monitor for reading current and voltage

7-   Power Circuit: Isolation contactor for each channel

8-   Output channel: 6 channels

9-   Output power per channel: 220 Volts * 45 AMP

10- Output power per channel: 10 KW [suitable for 3 standard ceramic pads rated

       at 3.4 kW & 65 Volts (for each pad) connected in a series circuit]

12-  Input cable: 4* 25

13- Output cable:  2*16

14- Place of Origin: Iran

15- Brand Name: TTS

16- Model Number: TTS.220.60.6

17- Recorded spot: 6 point (equipped by EL3000 Chino recorder)

18- Max. operation Temp: 1000 - 1200 °C

19- Application: PWHT, Temperature monitoring

20- Packaging: wooden boxes

21- Minimum order: 1 set

22- Delivery Detail: Feel free to contact us for information
